TECHNICAL CHARACTERISTICS
- Electronic transformers with dimmer for low voltage halogen lamps 12 V
- Heat resistance polyamide housing
- Ambiant operating temperature : < 50°C
- Maximal operating temperature : < 85°C
- Protection class II
- Thermal protection with fuse
- Short circuit current protection
- Screwed wires : 1 mm² at the input and 2,5 mm² at the output
- Safety Standards : EN-61347-2-2; EN-61047; EN-61547; EN-61000-3-2 ; EN-55015
PERFORMANCE TABLE
| Power (W) | Frequency (Hz) | Input voltage (V) | Output voltage (V) | Input current Max. (A) | Output current Max. (A) | Power factor |
|---|---|---|---|---|---|---|
| 20/60 | 50 | 220-240 | 11,5 | 0,26 | 5 | 0,99 |
