TLA -12/60

Image Gallery

[sigplus] Critical error: Image gallery folder 220 is expected to be a path relative to the image base folder specified in the back-end.

TECHNICAL CHARACTERISTICS

  • Security transformers with separated winding
  • Manufactured with double insulation to prevent any contact with low voltage components
  • Ambiant operating temperature : < 40°C
  • Maximal operating temperature: < 70 °C
  • Insolation group F (155 °C)
  • Rolling-up group H (180 °C)
  • Dielectric rigidity : > 2000 V
  • Predict an external slow melting fuse of 0,25 A
  • Safety Standards : NF EN-61 558-2-6 ; NF EN-61 558-2-4

PERFORMANCE TABLE

Power (VA) Frequency (Hz) Input voltage (V) Output voltage (V) Input current Max. (A) Output current Max. (A) Power factor
60 50/60 230 11,5 0,32 5 0,99
