TECHNICAL CHARACTERISTICS
- Luminaire designed for HPS- HPL/HID lamps
- Agree with the most strict lows of luminous pollution
- Protection degree IP 66 thanks to silicone gasket and integrated filter
- Protection degree against shock: IK 08
- Aluminum housing injected under pressure UNI EN 46100 with polyester paint after chrome treatment
- Wind surface: 0.12 m²
- Pure anodized and brilliant aluminum reflector
- Tempered glass resistant against mechanical stress
- Galvanized steel lamp holder bracket
- Variable fixation at the support head or on a spigot ɸ 48 mm or 58 mm
- Fixation on a 1 m cross width with an angle: 0 …15°
- Cable input : 10-14 mm with a stuffing box M 20
- Possibility to provide the luminaire, on request, by a double power regime ballast 150 W
PERFORMANCE TABLE
| Lamp | Lamp holder | Power (W) | Voltage (V)/ Frequency (Hz) | Weight max. (kg) | Height (m) | Efficiency (%) |
|---|---|---|---|---|---|---|
| HPL | E27 | 125 | 220-240 /50-60 | 5,7 | 6-8 | 82 |
| HPS/ HID | E27 | 70 | 220-240/ 50-60 | 6 | 6-8 | 82 |
| HPS/ HID | E40 | 100 | 220-240/ 50-60 | 6.3 | 6-8 | 82 |
| HPS/ HID | E40 | 150 | 220-240/ 50-60 | 6.6 | 7-10 | 82 |
