TECHNICAL CHARACTERISTICS
- Magnetic ballast for HPL/HID lamps 1000W
- Winding class H (200°C)
- Thermal class (tw) :130°C
- Max. increase of temperature above ambient temperature (ΔT) : 70°C
- Resin impregnation and oven drying
- Protection class I
- Capacitor compensation 80/100 μF ±10%
- Dielectric stiffness : > 3000 V
- Screw terminals : 0,75-2,5 mm²
- Safety standards: NF EN-61 347 & NF EN- 60 923
