TECHNICAL CHARACTERISTICS
- Magnetic ballast for flat or narrow lamps
- Resin impregnation and heating
- Protection class I
- Compensation with capacitors 2 μF ±10%
- Dielectric stiffness : > 1500 V
- Screw terminals : 0,75-2,5 mm²
- Safety Standards : NF EN-61 347 & NF EN- 60 921
PERFORMANCE TABLE
| Power (W) | Voltage (V) | Frequency (Hz) | Power factor | Weight (kg) | Current at 230 V (A) |
|---|---|---|---|---|---|
| 13 | 220-240 | 50 | 0,52 | 0,4 | 0,165 |
| 2*7 | 220-240 | 50 | 0,47 | 0,4 | 0,175 |
| 2*9 | 220-240 | 50 | 0,55 | 0,4 | 0,165 |
