Caractéristiques techniques
- Electronic ballasts for HID lamps with a total harmonic distortion (THD) < 15%
- Short circuit current and open circuit current protections
- Thermal and ignitor failure protections
- High life span of the lamp
- Silent ballasts (Sound Rated: group A)
- Housing maximal temperature: -15 / 80°C
- Regulation exigence : UL (class P/ type 1 outside), FCC (part 18, limited for EMI/RFI)
- Safety Standards : IEC-61347-2-3; EN-61347-1; EN-61547; EN-61000-3-2 ; EN-61000-3-3 ; EN-55015
PERFORMANCE TABLE
| Power (W) | Voltage (V) | Frequency (Hz) | Power factor | Ambiant temperature Max (°C) | Current at 230 V (A) | Crest factor |
|---|---|---|---|---|---|---|
| 35 | 220-240 | 50/60 | >0,98 | -15 / +80 | 0,185 | <1.8 |
