TECHNICAL CHARACTERISTICS
- Electronic ballasts for HID lamps with a total harmonic distortion (THD) < 11%
- Short circuit current and open circuit current protections
- Thermal and ignitor failure protections
- High life span of the lamp
- Silent ballast (Sound Rated: group A)
- Housing maximal temperature: -15 / 80°C
- Regulation exigence : UL (class P/ type 1 outside), FCC (part 18, limited for EMI/RFI)
- Safety Standards : IEC-61347-2-3; EN-61347-1; EN-61547; EN-61000-3-2 ; EN-61000-3-3 ; EN-55015
PERFORMANCE TABLE
| Power (W) | Voltage (V) | Frequency (Hz) | Power factor (V) | Ambiante temperature Max (°C) | Current at 220 V (A) | Crest factor | Dimensions (mm) | ||
|---|---|---|---|---|---|---|---|---|---|
| L | I | H | |||||||
| 150 | 220-240 | 50/60 | >0,98 | -15/+80 | 0,76 | <1,6 | 183 | 91 | 38 |
