ELECTRONIC BALLASTS EBT8-226

Image Gallery

[sigplus] Critical error: Image gallery folder 207 is expected to be a path relative to the image base folder specified in the back-end.

TECHNICAL CHARACTERISTICS

  • Electronic ballast for rapid starting fluorescent lamp without starter
  • Fuse protection
  • Protection class II
  • Constant luminous flux
  • Total harmonic distortion < 15 %
  • High life span of the lamp
  • Low energy consumption
  • Silent ballast
  • Safety Standards : IEC-61347-2-3; EN-61347-1; EN-61547; EN-61000-3-2 ; EN-61000- 3-3 ; EN-55015

PERFORMANCE TABLE

Power (W) Voltage (V) Frequency (Hz) Power factor Current at 230 V (mA) Temperature Min / Max (°C) Life span (h) Crest factor
2*26 220-240 50/60 230 0,97 -10 / +50 30 000 1.7
